April 9, 2020 Promotion

GenV HyperGate45 Lite Now Available

Available Now!!!

TS-0553-1602 Hypergate45
Hyper Gate 45 Standard (Red) VS LITE (Black) side by side height and length comparison
Hyper Gate 45 Standard (Red) VS LITE (Black) side by side height and length comparison

GenV External Wastegate Range

The GenV External Wastegate Range from Turbosmart has been around since its release at SEMA 2017. When the ground up range re-design hit the market, each gate was optimized for industry-leading flow, fatigue & heat resistance, ensuring if you had yourself a GenV External Wastegate, you had the smallest, lightest, most reliable and resilient external wastegate for your application.

Industry-leading Flow & Performance

In 2020 Turbosmart will continue to expand on the GenV range introducing the HyperGate45 Lite. The HyperGate45 Lite retains the HyperGate45’s industry-leading flow and thermal performance while using a smaller actuator housing for increased fitment opportunities in modern, cramped engine bays. This reduced overall size & weight does incur a penalty in terms of control. However, it is a small price to pay if real estate in your engine bay is limited. Refer Image above, where the HyperGate45 (in Red) sits next to the Hyerpgate45 Lite (in Black).

Why is Actuator Size Important?

Think about it in terms of leverage: A large spanner or wrench versus a short one. The larger one gives you leverage and means you can do more work with more control, and the shorter one requires more effort and provides less control. The same goes for the actuator size relative to the size of your wastegate valve. The GenV range of actuators is carefully matched to valve size to meet an extremely capable ratio for unbeatable wastegate control.

HyperGate45 Lite 7psi Black
TS-0553-1602
Shop Now
HyperGate45 Lite 14psi Black
TS-0553-1612
Shop Now
Previous
Next

Features

The HyperGate45 Lite features the small frame actuator housing of our motorsport proven 45mm CompGate 45 range, with the CFD driven and marketing leading flow of the HyperGate45 body that takes advantage of the modular nature of the Turbosmart GenV Wastegate range. Refer to Technical Drawings below. You can easily see the height difference (109mm vs 116mm) and the actuator width (75mm vs 84mm).

HyperGate45 Diagram

Availability

The GenV HyperGate45 Range is available in a host of actuator specifications, including StandardMotorsportCompressed GasHigh Pressure, Positions Sensor Options and Electronic. Check out the full range on our website to ensure you have the right valve for the job and don’t hesitate to reach out if you require any other information.

Find your nearest dealer or contact Turbosmart direct for further information: www.turbosmart.com

Frequently Asked Questions

The Turbosmart GenV range is designed around industry and peer flange orientation. If you have a valve of similar size, it’s likely we have a valve that swaps right in. If in any doubt, please contact us and ask, we’re only too happy to help.

All GenV External Wastegates from Turbosmart are liquid cooled. That doesn’t have to mean water or coolant by the way, there are other liquids in your driveline you can use – That’s up to you. But yes, like the normal HyperGate45’s, the HyperGate45’s still incorporates optional liquid cooling.

In ‘normal’ applications, your wastegate can run 2-3 times base mechanical spring pressure with boost control and manipulation of the reference signal if asked to. With the reduced actuator housing size of the HyperGate45 Lite, this will be reduced. Your application will depend on how much but expect approximately two times base pressure instead of 3.

Yes, absolutely. Rotating housing, liquid cooling provision, industry-leading flow and fatigue resistance and composite thermal insulation, Stainless Strap Band clamps are all featured across the range, including the HyperGate45 Lite.

Here is a handy self-help guide to helping you with your Turbosmart install and answers to some of the most frequently asked questions we get here. Turbosmart recommends that you get your products fitted and tuned by a qualified technician. If you choose to fit and set the product up yourself, ensure you have all the necessary tools and technical knowledge required to perform this task.

Thank you for picking up the latest Turbosmart catalogue. As we look back on 22 fantastic years of innovation and growth, we continue to look towards the future, as we release some revolutionary new products that will cement our reputation as an innovator and market leader.

Please contact us here and fill out a quick form so that our team can help you in an efficient way!

Product Advisor

Try Out Our New Product Advisor!

This tool is designed to remove some of the mystery of how to choose the right Wastegate, Blow-off Valve and Fuel Pressure Regulator, for your project.
Try Now!!!

Award-Winning Turbo Technology

Turbosmart External Wastegate Range

Our new GenV wastegates are a direct fit upgrade to all 4th-generation Turbosmart wastegates. All GenV wastegates are provided with a range of springs (3-26psi). In addition, they feature our unique collar-locking system, rotatable actuator, strap-type V-band clamps, 1/8″ NPT ports, and “optional” liquid-cooling. They are also available in Motorsport and Compressed Gas versions.
